Components and Circuits Characterization
Vector Network Analyzer (VNA)
– N5247 PNA-X 10 MHz – 67 GHz coaxial
– VDI extenders up to 1.1 THz:
– 50-75 GHz – 220-330 GHz
– 75-110 GHz – 325-500 GHz
– 90-140 GHz – 500-750 GHz
– 140-220 GHz – 750-1100 GHz
– N5291A PNA up to 120 GHz (1mm)
– N5244 PNA up to 43.5 GHz
– Anritsu VNA 37369D up to 40 GHz
All the probing equipment you need
– Suss Microtech semi-automatic Prober
– 50 GHz to 1.1 THz (2-Ports)
– 10 MHz to 67 GHz (4-ports)
– MPI 150 Manual prober
– Lakeshore: Cryogenic prober down to 4 Kelvin
We have all the tools to characterize your antenna
Freqency range: 800 MHz to 6 GHz
NSI-MI Compact Range 4-110 GHz
NSI-MI Near/Far Field 110-750 GHz
Circuits Characterization
Infiniium UXR Oscilloscope up to 110Ghz
Signal Generator 67 GHz
Up to 750 GHz with VDI extenders
Spectrum Analyzer up to 67 GHz
Up to 750 GHz with VDI mixers
